| Model |
NTS-IPM3178E-AD |
NST-IPM3175E-AD-F |
NST-IPM75255 |
| Camera Type | Full Color Night Vision Dome IP Camera |
|---|
| System | Embedded RTOS design |
|---|
| Effective Pixels | 8.0 MP | 5.0 MP | 5.0 MP |
|---|
| Main Stream | 3840×2160@20fps | 2592×1944@20fps, 2560×1440@25fps | 1920×1080@25fps |
|---|
| Sub Stream | 1280×720@25fps, 704×576@25fps | 704×576@25fps | 704×576@25fps |
|---|
| Image Sensor | Sony IMX415 CMOS | Sony IMX335 CMOS | Sony IMX307 CMOS |
|---|
| Chipset | Mstar SSC328Q | Mstar SSC30KD | Mstar SSC335 |
|---|
| Min. Illumination | Color: 0.01Lux, B/W: 0.0001Lux | Color: 0.01Lux, B/W: 0.001Lux | Color: 0.01Lux, B/W: 0.01Lux |
|---|
| Adjustable Params | DWDR, BLC, DNR, AE, AGC, D&N, Mirror, Flip |
|---|
| Video Compression | H.265/H.264, Dual stream, AVI format |
|---|
| Bit Rate | 0.1M ~ 8Mbps adjustable |
|---|
| Frame Rate | 1 ~ 30fps adjustable |
|---|
| Audio I/O | Built-in Mic and Speaker |
|---|
| Audio Compression | G.711, two-way intercom, synchronized AV |
|---|
| Alarm Types | Motion Detection, Video Blind, Video Loss |
|---|
| Web Browser | IE, Chrome, Safari, Firefox |
|---|
| Mobile Monitoring | iPhone, Android |
|---|
| CMS Software | Uniform CMS (multi-device support) |
|---|
| Cloud P2P | Supported (MYEYE platform) |
|---|
| Network Protocols | RTSP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, SMTP |
|---|
| ONVIF | Supported (2.4) |
|---|
| POE | Supported (optional) |
|---|
| Languages | 20+ including English, French, Russian, etc. |
|---|
| Lens | Board Lens 3.6mm |
|---|
| Lighting | 2pcs Warm Light LEDs |
|---|
| IR Distance | 20m |
|---|
| Infrared Wavelength | 580nm |
|---|
| IR Cut Filter | Double light switch IR-CUT filter |
|---|
| Waterproof | IP66 |
|---|
| Connectors | 1× DC, 1× RJ45 (10/100M) |
|---|
| Power Supply | DC12V / PoE (802.3af/at) |
|---|
| Power Consumption | IR On: 600mA max, IR Off: <200mA |
|---|
| Working Temp | -10°C ~ +60°C, 10–90% RH (Heater optional < -20°C) |
|---|
| Weight | 0.6kg |
|---|
